How to Set Up Burp Suite Proxy on Rooted Android with AlwaysTrustUserCerts (Magisk)
I'm a Security Analyst in cybersecurity, focused on keeping applications safe and identifying vulnerabilities. I specialize in application security, analyze and fortify systems against threats, and communicate effectively in fast-paced environments. I've excelled in CTF challenges, showcasing my ability to tackle complex security issues, and I'm committed to continuous learning and innovation in the field.
Setting up Burp Suite with Android devices or emulators can be annoying, especially on newer Android versions where user-installed certificates are not trusted by many apps by default.
There are many ways to solve this, but I used a lesser-known and very easy method using a Magisk module called AlwaysTrustUserCerts.
This guide explains the process.
Requirements
Before starting, you need:
Burp Suite installed on your system
An Android device or emulator
Root access on the Android device
Magisk installed
AlwaysTrustUserCerts Module installed in Magisk
OpenSSL installed on your system
The Android device and Burp machine connected to the same network
Use this only on devices, apps, and traffic you own or are authorized to test.
Step 1: Export the Burp Suite Certificate
First, open Burp Suite.
Go to:
Proxy > Proxy settings > Import / export CA certificate
Export the certificate in DER format.
Save it with a name like:
burp.der
Step 2: Convert the Certificate to PEM Format
Android can install certificates from different formats, but for this method I converted the Burp certificate to .pem.
Run:
openssl x509 -inform DER -in burp.der -out burp.pem
Now you should have:
burp.pem
Step 3: Move the Certificate to the Android Device
Transfer the burp.pem file to your Android device.
You can use adb push:
adb push burp.pem /sdcard/Download/
Or you can copy it manually using file transfer.
Step 4: Install the Certificate as a User Certificate
On the Android device, go to:
Settings > Security > Encryption & credentials > Install a certificate
The exact path may differ depending on the phone or Android version, but it is usually under Security or Privacy/Security settings.
Select the burp.pem file and install it as a CA certificate.
At this point, the certificate is installed as a user certificate.
However, many Android apps do not trust user-installed certificates. This is where the useful part comes in.
Step 5: Install AlwaysTrustUserCerts Magisk Module
Download the AlwaysTrustUserCerts Module from Github Releases : Click To Download
Open Magisk and install the module:
AlwaysTrustUserCerts
This module moves or links user-installed CA certificates into the system trusted certificate store, making Android treat them like system certificates.
After installing the module:
Enable the module
Reboot the device
After reboot, confirm the Burp certificate appears under trusted credentials
Now your Burp certificate should be trusted system-wide.
Step 6: Configure Android Proxy
Now set the Android device to use Burp Suite as its proxy.
Option 1: Set Proxy from Wi-Fi Settings
Go to your connected Wi-Fi network settings and set:
Proxy: Manual
Host: Your Burp machine IP
Port: 8080
Example:
Host: 192.168.1.10
Port: 8080
Make sure Burp is listening on the same port.
Option 2: Set Proxy Using ADB
You can also configure the proxy with ADB:
adb shell settings put global http_proxy 192.168.1.10:8080
To remove the proxy later:
adb shell settings put global http_proxy :0
Step 7: Start Intercepting Traffic
In Burp Suite, make sure your proxy listener is active and bound to an interface reachable by the Android device.
Now open an app or browser on Android and check Burp.
You should start seeing HTTP and HTTPS traffic.
Notes
Some apps may still not work if they use certificate pinning. In that case, you may need additional bypass methods such as Frida, Objection, or app patching.
But for many apps and browser traffic, this setup works nicely and avoids manually pushing certificates into Android’s system certificate directory.
Conclusion
The usual Android Burp certificate setup can be painful, especially on modern Android versions. Using Magisk with the AlwaysTrustUserCerts module makes the process much easier.
The flow is simple:
Export Burp cert > Convert to PEM > Install as user cert > Enable AlwaysTrustUserCerts > Reboot > Set proxy
After that, your Android device should trust Burp’s CA certificate and route traffic through Burp Suite successfully.
